Multi-Gigabit copper access
Connect compatible 2.5G and 5G devices through 48 RJ45 ports, with four high-speed fiber uplinks.
Model: EW-S57948QM
48-Port 2.5G/5G L3 Switch with 4 100G Uplinks
- 48 × 2.5G/5G RJ45 ports + 4 × 40/100G uplinks
- 1.28 Tbps switching capacity · 952 Mpps
- IPv4 static routing, RIP, OSPF and BGP
Project inquiry
Request pricing and lead time
Tell us your model, quantity and project requirements. Our networking team will help you find the right fit.
Overview
EW-S57948QM provides 48 multi-Gigabit copper ports and four 40/100G fiber uplinks for enterprise and campus networks. IPv4 routing, VLAN, ACL and QoS functions support access and aggregation in a 1U rack chassis.
Routed network control
IPv4 routing, VLAN segmentation, ACL filtering and eight QoS queues support network policy.
Central administration
Dedicated management and console ports complement Web, CLI and SNMP access.
| Specification | Details |
|---|---|
| Model | EW-S57948QM |
| Copper ports | 48 × 2.5G/5G RJ45 data ports |
| Fiber uplinks | 4 × 40/100G fiber slots |
| Switching capacity | 1,280 Gbps |
| Forwarding rate | 952 Mpps |
| MAC address table | 112K entries |
| IPv4 routing | Static/default routes, RIP v1/v2, OSPF and BGP |
| Management interfaces | 1 console port + 1 dedicated management port |
| Power input | 100–240V AC, 50/60Hz |
| Power consumption | 150W, as listed in the datasheet |
| Dimensions / weight | 440 × 300 × 44 mm; 7kg |
| Operating environment | 0 to +40°C; 10–90% RH, non-condensing |
| Warranty | 3 years |
Order information
| Content | Quantity | Unit |
|---|---|---|
| EW-S57948QM managed Ethernet switch | 1 | SET |
| Rack-mount brackets | 1 | PAIR |
| User guide | 1 | PCS |
| Warranty card | 1 | PCS |
EW-S57948QM Resources
PDF · Specifications · Installation · Ordering
