Four fiber links
Use compatible SFP modules to connect remote network segments.
Model: EW-S3906G
6-Port Gigabit Fiber Switch with 4 SFP and 2 RJ45 Ports
- 4 Gigabit SFP fiber ports
- 2 Gigabit RJ45 copper uplinks
- 12Gbps switching; 8K MAC table
- Compact IP30 enclosure; 1-year warranty
Project inquiry
Request pricing and lead time
Tell us your model, quantity and project requirements. Our networking team will help you find the right fit.
Overview
EW-S3906G connects four Gigabit SFP fiber links to two Gigabit copper uplinks. A compact IP30 enclosure, 12Gbps switching capacity and 8K MAC table support small fiber aggregation networks.
Two copper uplinks
Gigabit RJ45 interfaces connect upstream equipment and recording systems.
Compact enclosure
The 202 × 140 × 65 mm housing fits small access-network installations.
| Specification | Details |
|---|---|
| Model | EW-S3906G |
| Fiber ports | 4 × Gigabit SFP |
| Copper uplinks | 2 × 10/100/1000Mbps RJ45 |
| Switching capacity | 12Gbps |
| MAC table | 8K entries |
| Forwarding | Store and forward |
| Power specification | 12V DC |
| Standby consumption | Below 4W |
| Dimensions | 202 × 140 × 65 mm |
| Enclosure | IP30 |
| Operating temperature | −20°C to +55°C |
| Warranty | 1 year |
Order information
| Content | Quantity | Unit |
|---|---|---|
| EW-S3906G fiber switch | 1 | SET |
| User guide | 1 | PC |
| Warranty card | 1 | PC |
EW-S3906G Resources
Datasheet and configuration information for this product are available from the EWIND team.
