Copper and fiber access
Connect PoE endpoints and eight Gigabit fiber links on one switch.
Model: EW-S5736GM-8GF-AP
36-Port Managed PoE Switch with 8 Gigabit SFP and 4 10G Uplinks
- 24 Gigabit PoE + 8 Gigabit SFP + 4 10G SFP+
- IEEE 802.3af/at; up to 30W per port
- 400W built-in AC supply
- Static routing, VLANs, ERPS and PoE scheduling
Project inquiry
Request pricing and lead time
Tell us your model, quantity and project requirements. Our networking team will help you find the right fit.
Overview
EW-S5736GM-8GF-AP combines 24 Gigabit PoE access ports, eight Gigabit SFP ports and four 1G/2.5G/10G SFP+ uplinks. A 400W power configuration, static routing and managed PoE controls serve mixed copper and fiber access networks.
Scheduled PoE
Monitor power and control each access port with limits, priority and schedules.
Managed aggregation
Four SFP+ uplinks, static routes and redundancy protocols support larger access networks.
| Specification | Details |
|---|---|
| Model | EW-S5736GM-8GF-AP |
| PoE ports | 24 × Gigabit RJ45; IEEE 802.3af/at |
| Fiber ports | 8 × 100/1000Mbps SFP |
| Uplinks | 4 × 1G/2.5G/10G SFP+ |
| Per-port power | Up to 30W |
| Power supply | 400W; AC 100–220V, 50–60Hz |
| Management | L3 managed; static routing, web, CLI and SNMP |
| Forwarding rate / MAC table | 107.14Mpps / 32K entries |
| Dimensions | 440 × 290 × 44.5 mm |
| Installation | Desktop or 19-inch 1U rack |
| Operating temperature | −20°C to +55°C |
| Warranty | 3 years |
Order information
| Content | Quantity | Unit |
|---|---|---|
| EW-S5736GM-8GF-AP switch, 400W configuration | 1 | SET |
| Rack mounting brackets | 1 | PAIR |
| User guide | 1 | PC |
| Warranty card | 1 | PC |
EW-S5736GM-8GF-AP Resources
PDF · Specifications · Installation · Ordering
