60W power
Support a higher-power endpoint from a single AC-powered injector.
Model: EW-PSE101G-AC-60
60W Gigabit PoE Injector with AC Input
- Single 60W Gigabit PoE output
- IEEE 802.3af/at/bt compatibility
- 100–240VAC input; 52V output
- Fanless desktop or wall installation
Project inquiry
Request pricing and lead time
Tell us your model, quantity and project requirements. Our networking team will help you find the right fit.
Overview
EW-PSE101G-AC-60 delivers up to 60W of PoE over a single Gigabit Ethernet output. It supports IEEE 802.3af/at/bt devices and runs directly from 100–240VAC, providing a compact way to add power to an existing Ethernet connection.
Gigabit data
Connect the data input to an existing Gigabit Ethernet switch.
Thermal cutoff
Integrated over-temperature and network-port ESD protection.
Compact housing
108 × 44 × 33mm enclosure for desktop or wall mounting.
| Specification | Details |
|---|---|
| Ports | 1 × Gigabit data input; 1 × Gigabit PoE output; 1 × AC input |
| PoE standard | IEEE 802.3af/at/bt |
| PoE output | 60W; 52V |
| Power input | 100–240VAC, 50–60Hz |
| Dimensions / weight | 108 × 44 × 33mm; 0.14kg |
| Installation | Desktop or wall mounted; fanless |
| Operating environment | −20°C to +55°C; 10%–90% RH, non-condensing |
| Warranty | 1 year |
Order information
| Content | Quantity | Unit |
|---|---|---|
| EW-PSE101G-AC-60 60W Gigabit PoE injector | 1 | SET |
| User guide | 1 | PC |
| Warranty card | 1 | PC |
