Model: EW-S1810GU-AP

10-Port Fast Ethernet Hi-PoE Switch with Gigabit Uplinks

8 × 10/100Mbps PoE ports plus 2 × Gigabit uplinks
Ports 1–6 support IEEE 802.3af/at; ports 7–8 support af/at/bt up to 60W
120W total PoE budget with built-in AC power supply
AI Extend up to 300m, port isolation/VLAN and PoE watchdog modes

Project inquiry

Request pricing and lead time

Tell us your model, quantity and project requirements. Our networking team will help you find the right fit.

info@ewindnet.com

Overview

EW-S1810GU-AP combines eight 10/100Mbps PoE ports with two Gigabit RJ45 uplinks and a 120W built-in AC supply. Ports 7–8 support 60W Hi-PoE, while selectable AI Extend, isolation and PoE watchdog modes simplify long-reach surveillance networks.

Hi-PoE ports

Ports 7–8 deliver up to 60W each for PTZ cameras and other high-power endpoints.

Gigabit uplinks

Two 10/100/1000Mbps RJ45 uplinks connect NVRs and aggregation switches.

300m Extend

AI Extend supports long-distance camera links with automatic speed adjustment.

Smart protection

Isolation, VLAN and PoE watchdog modes help maintain CCTV availability.

Product technical specifications
Specification	Details
Interfaces	8 × 10/100Mbps PoE RJ45; 2 × 10/100/1000Mbps uplink RJ45
PoE capability	Ports 1–6 IEEE 802.3af/at; ports 7–8 IEEE 802.3af/at/bt; 30W standard, 60W max on ports 7–8
PoE budget	120W total
Switching performance	5.6Gbps; 4.17Mpps; store-and-forward
Memory	4K MAC table; 1.25M buffer
Power supply	Built-in 100–240VAC, 50–60Hz, 120W
Long-reach modes	AI Extend up to 300m; automatic 10Mbps on extended port while other ports remain standard speed
Dimensions / weight	195 × 130 × 40mm; net under 1kg, gross under 1.2kg
Installation	Desktop or wall mounted
Environment / protection	Operating −20°C to +55°C; storage −40°C to +75°C; IP30 and ESD/surge protection
Warranty	2 years; lifetime maintenance
