Fiber uplinks up to 10G
Four SFP+ slots connect access traffic to the upstream network.
Model: EW-S5728GM
24-Port Gigabit L3 Managed Switch with 4 10G SFP+ Uplinks
- 24 Gigabit RJ45 data ports
- 4 × 1G/2.5G/10G SFP+ uplinks
- Static routing and IPv4/IPv6 management
- 32K MAC table; 3-year warranty
Project inquiry
Request pricing and lead time
Tell us your model, quantity and project requirements. Our networking team will help you find the right fit.
Overview
EW-S5728GM provides 24 Gigabit data ports and four 1G/2.5G/10G SFP+ uplinks. Static routing, VLANs, ERPS and traffic controls support managed access and aggregation, with web, CLI and SNMP administration.
Static routing
Configure inter-VLAN communication with static and default routes.
Redundancy and access control
ERPS, spanning tree, ACLs and authentication support managed network designs.
| Specification | Details |
|---|---|
| Model | EW-S5728GM |
| Access ports | 24 × 10/100/1000BASE-T RJ45; data only |
| Uplinks | 4 × 1G/2.5G/10G SFP+ |
| Management | L3 managed; web, CLI and SNMP |
| Routing | Static/default routes; up to 128 entries |
| MAC table | 32K entries |
| Console | RS232; 115200 baud, N/8/1 |
| Power input | AC 100–220V, 50–60Hz; built-in supply |
| Dimensions | 440 × 290 × 44.5 mm |
| Installation | Desktop or 19-inch 1U rack |
| Operating temperature | −20°C to +55°C |
| Warranty | 3 years |
Order information
| Content | Quantity | Unit |
|---|---|---|
| EW-S5728GM switch | 1 | SET |
| Rack mounting brackets | 1 | PAIR |
| User guide | 1 | PC |
| Warranty card | 1 | PC |
EW-S5728GM Resources
PDF · Specifications · Installation · Ordering
