Copper and fiber uplinks
Two Gigabit RJ45 ports and two SFP slots connect the access network to upstream equipment.
Model: EW-PIS1712-8FE
8-Port Fast Ethernet Industrial PoE Switch with 4 Gigabit Uplinks
- 8 × 10/100Mbps IEEE 802.3af/at PoE ports
- 2 × Gigabit RJ45 + 2 × 100/1000Mbps SFP uplinks
- Up to 30W per PoE port
- 48–57V DC redundant inputs; DIN-rail mounting
Project inquiry
Request pricing and lead time
Tell us your model, quantity and project requirements. Our networking team will help you find the right fit.
Overview
EW-PIS1712-8FE connects eight Fast Ethernet PoE devices with two Gigabit RJ45 and two 100/1000Mbps SFP uplinks. IEEE 802.3af/at power, redundant DC inputs and DIN-rail mounting support industrial camera, wireless and sensor networks without software configuration.
Eight PoE connections
Power compatible cameras, access points and sensors with up to 30W per port.
Industrial installation
IP40 enclosure, redundant DC terminals and DIN-rail mounting suit control cabinets.
| Specification | Details |
|---|---|
| PoE ports | 8 × 10/100Mbps RJ45 |
| Uplink ports | 2 × 10/100/1000Mbps RJ45; 2 × 100/1000Mbps SFP |
| Management | Unmanaged; DIP-switch functions |
| PoE standard / output | IEEE 802.3af/at; up to 30W per port |
| Switching / forwarding | 9.6Gbps; 7.14Mpps at 64 bytes |
| MAC table / buffer / jumbo frame | 8K entries / 2M / 10K |
| Power input | 48–57V DC; redundant 5-pin terminal; reverse-polarity protection |
| Power supply | Not included; optional 48V 120W or 240W supply |
| Operating temperature | −40 to +75°C |
| Enclosure / mounting | IP40; DIN rail |
| Warranty | 5 years |
Order information
| Content | Quantity | Unit |
|---|---|---|
| EW-PIS1712-8FE industrial PoE switch | 1 | SET |
| User guide | 1 | PC |
| Warranty card | 1 | PC |
