Model: EW1800

WiFi 6 AX1800 Gigabit Wireless Router

Dual-band 802.11ax up to 1800Mbps total
1 Gigabit WAN + 4 Gigabit LAN ports
Mesh, relay and fast-roaming support
WPA3, MU-MIMO, OFDMA and beamforming

Project inquiry

Request pricing and lead time

Tell us your model, quantity and project requirements. Our networking team will help you find the right fit.

info@ewindnet.com

Overview

EW1800 is a dual-band WiFi 6 router with up to 574Mbps on 2.4GHz and 1201Mbps on 5GHz. Five Gigabit Ethernet ports, Mesh and relay modes, WPA3 security and support for up to 128 connected users suit homes, shops and small offices.

WiFi 6 dual band

574Mbps at 2.4GHz plus 1201Mbps at 5GHz.

Five Gigabit ports

One WAN and four LAN ports for wired devices.

Mesh coverage

Mesh, relay and 802.11k/v/r roaming features.

Secure access

WPA3-PSK, firewall, DoS protection and guest networking.

Product technical specifications
Specification	Details
Wireless standard	IEEE 802.11a/b/g/n/ac/ax
Wireless rate	2.4GHz up to 574Mbps; 5GHz up to 1201Mbps; total 1800Mbps
WAN	1 × 10/100/1000Mbps
LAN	4 × 10/100/1000Mbps
Antennas	4 × 5dBi external antennas
Memory	256MB DDR2; 128MB flash
Connected users	Up to 128
Power adapter	12V DC, 1A
Operating / storage temperature	−10°C to +45°C / −20°C to +70°C
Working modes	Routing or bridge
Management	Chinese, English, Spanish and Russian web management; TR-069

Advanced capabilities

Detailed network functions stay available here without interrupting the main selection path.

Wireless features

WiFi 6 functions include OFDMA, uplink/downlink MU-MIMO, BSS coloring, beamforming, 1024-QAM, STBC and LDPC. Actual throughput varies with client capability, channel conditions and traffic.

Mesh and roaming

Mesh roles can be automatic, main router or satellite. Relay mode, fast roaming and IEEE 802.11v/r support help extend coverage across larger spaces.

Network services

WAN supports dynamic IP, static IP and PPPoE. IPv6, DHCP, DDNS, IPTV, VPN client, port forwarding, DMZ, MAC/IP filtering, guest network and parental controls are available in the software.

Security and administration

WPA3-PSK, firewall, DoS/DDoS protection, blacklist/whitelist, URL control, WPS and scheduled wireless operation. Web management also provides logs, firmware upgrade, backup/restore and LED control.

Environmental limits

Operating humidity: 10–90%, non-condensing. Storage: 5–90%, non-condensing. Reset requires a long press of 6 seconds; WPS is available for quick pairing.
