Model: EW-810GM-2

10/100/1000M Fiber Media Converter

10/100/1000Mbps full-duplex operation on both TX and FX ports
One RJ45 port and one dual-fiber SC port with Auto MDI/MDIX on the TX port
Source technical table lists 2km fiber distance; module-dependent application reach is noted in the PDF
Force/Auto transfer mode, link indicators and less than 3W power consumption

Project inquiry

Request pricing and lead time

Tell us your model, quantity and project requirements. Our networking team will help you find the right fit.

info@ewindnet.com

Overview

EW-810GM-2 provides a Gigabit Ethernet-to-fiber bridge with 10/100/1000Mbps RJ45 support, dual-fiber SC connectivity and source-listed 2km technical distance. Its application diagrams cover remote network interconnection and CCTV with 2U rack aggregation.

Gigabit conversion

One RJ45 port and one dual-fiber SC port bridge copper and optical Ethernet.

10/100/1000Mbps

Full-duplex operation supports Gigabit Ethernet on both TX and FX ports.

Fiber backbone

Source technical data lists 2km distance, with reach determined by the selected fiber module.

Flexible installation

Auto MDI/MDIX, Force/Auto FX mode, status LEDs and low power draw.

Product technical specifications
Specification	Details
Optical interface	Dual-fiber SC port; SM 9/125μm fiber listed in the source
Copper interface	RJ45; 10/100/1000Mbps; Cat5 or Cat6 cable; Auto MDI/MDIX
Duplex mode	Full duplex on TX and FX; half/full duplex on the RJ45 interface
Fiber distance	2KM in the source technical table
Wavelength	MM 1310nm as listed in the source technical table
Power	Adapter type: DC5V; built-in power type: AC100 ~ 240V
Power consumption	＜3W
Indicators	PWR, FDX, Fiber/RJ45 LINK/ACT, 100M and 1000M indicators
Environment	Operating 0 ~ 50℃; storage −40 ~ 70℃; 5 ~ 95% RH, non-condensing
MTBF	≥10.0000h
Compliance	CE, FCC and RoHS
Warranty	3-year warranty

Advanced capabilities

Detailed network functions stay available here without interrupting the main selection path.

Fiber link planning

The converter uses a dual-fiber SC interface. The technical specification lists SM 9/125μm fiber, MM 1310nm and 2KM distance. The application paragraph in the source says up to 120km, so the final reach should be confirmed against the selected module before publication.

Copper and transfer modes

The RJ45 port supports 10/100/1000Mbps, Cat5 or Cat6 cable and Auto MDI/MDIX. The FX port can use Force or Auto transfer mode.

Power and form factors

The source documents an adapter version with DC5V input and a built-in version with AC100 ~ 240V input. It lists 0.39kg / 94 x 70.5 x 26.5mm for the adapter version and 0.67kg / 140.5 x 111 x 30cm for the built-in version.

Deployment use

Source-listed applications include remote Ethernet nodes, fiber backbones, CCTV surveillance and standalone or 2U rack installation.
